High quality 60kva 48kw 3 phase in and out 60kva equipment online ups

  • 50 - 149 Pieces
    $5,677.60
  • 150 - 299 Pieces
    $5,504.50
  • 300 - 499 Pieces
    $5,388.00
  • >=500 Pieces
    $5,274.60
Output Voltage:
100/110/120/127/220/230VAC+/-10%
Shipping:
Support Express · Sea freight · Land freight · Air freight
Lead Time:
Quantity(Pieces) 1 - 1 2 - 2500 >2500
Est. Time(days) 2 21 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
ECSUN /OEM/ODM
Model Number:
33-60K
Phase:
Three Phase
Protection:
overload,over current,over voltage,short circuit,unbalance load
Weight:
294 kgs
Type:
On-line
Application:
Security / Monitoring / Alarm
Product name:
Low Frequency Online UPS
Battery UPS Capacity:
60KVA/48KW
Input Voltage Range:
210~475VAC±5
Input Frequency Range:
(40~70)±0.5Hz
Output Voltage:
380VAC/220AC
Transfer Time:
0 ms
Wave Form:
pure sine wave THD <3%(Linear load) THD <8%(non linear load)
Power factor:
0.80
Output Crest Ration:
3:1
HS Code:
8504402000
Product Certification certification
CE Certified.
Valid from 2017-01-04 until 2049-12-31
RoHS Certified.
Valid from 2017-01-04 until 2049-12-31
Supply Ability
Supply Ability:
60000.0 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
High quality 60kva 48kw 3 phase in and out 60kva equipment online ups
Unit dimension(D*W*H mm):820*440*1160
Box dimension(D*W*H mm):950*560*1333
Net Weight(kgs):294
Gross Weight(kgs):314
qty per marster cartons:1 pcs
Port
Shenzhen
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 1 2 - 2500 >2500
Est. Time(days) 2 21 To be negotiated

 High quality 60kva 48kw 3 phase in and out 10kva equipment online ups





Product Descriptions:
3C3 EX Series adopts double conversion structure, it is three-phase high frequency online UPS; The products are widely applied in small & medium data centers, network management centers, enterprise server rooms and general industrial environment. UPS power supply protect your critical equipments and provide a good solution from the most common power problems including the grid power outages, power failures, utility power overvoltage or brownouts , power transient sags or decrease shocks, high voltage spikes, voltage variations, voltage surges, harmonic distortions, line noise, frequency variations, etc. UPS power supply provides safe and reliable power protection for the user’s load.

Product Features
Excellent industrial environments protection performance
Front operation and front maintenance function .
Excellent electrical properties
N + X parallel redundancy (supports ups parallel co-battery)
High guaranteed dual utility power input function
High-performance DSP processor
Multiple remote monitoring and controlling methods
Intelligent management of battery charging and discharging
More flexible battery quantity configuration

Technical Parameters



Detailed Specifications Work way    Online supply power, static bypass switch, double conversion technology
Input Phase     Three phase + N + G
Input voltage    380VAC ± 25%
Input frequency    50Hz ± 10%,
Soft start    0 – 100%    5 second
Battery capacity and qty    32 piece ( 40 piece) / 12 V serial
Battery voltage    384 VDC (480 VDC)
Float voltage     405 VDC (540 VDC)
Charging current    1 A – 40 A (installed according to battery capacity)
Rated power    Standard capacity x 0.8
Output phase    Three phase + N + G
Output voltage    380 VAC  ± 1% (steady-state load);  380 VAC  ± 5% (influenced by load)
Output frequency    50Hz  ± 0.05%, 60Hz ± 0.05%  (battery supply)
Crest factor    3 : 1
Output wave form    Pure sine wave
Total Harmonic Distortion    Linear load < 2%, nonlinear load < 5%
Dynamic voltage transient    < ± 5%
Instant recovery time    < 10ms
Balance load voltage    < ± 1%;    < ± 5%  (unbalance load voltage)
Overload ability    125%:  1 minute,    150%:   1 second
Inverter efficiency    >   91%
Transfer time    0  ms
Communication connector  RS 232,  485 communication management,  stem node
Temperature  0 – 40 ℃
Humidity  30% - 90%
Service altitude    < 1000 meter (each additional 100 meters with 1% decline of power, the highest is 4000 meters)
Noise (dB) 45 - 55
Size (cm) 82.1 x 43.2 x 11.6
Weight (KG) 320kg
Option accessories Parallel module, harmonic filter, input isolation transformer, smart monitor software, SNMP adaptor
Application  1. Computers
2. Home Appliance, such as Fans and lights
3. Office, like computers with Printers
4. Aeronaoutics & Astronautics
5. Electronic & Telecom
6. Army Technology
7. Securities System
    8. Sensitive Electronic Equipment
9. Wind Power System
10. Production Equipment
11. Military
12. Medical Systems
13. Network
14. Instrumentation
15. Servers and so on
Standard package    wooden cabinet packing
Production ability    1000 Piece/Pieces per Month
Delivery time    Quantity > 5 pcs by sea, shipping time: 20 - 35 days;
   Quantity < 5 pcs by air, shipping time: 5 - 12 days
Delivery port    SHENZHEN

Details please referto the user manual

Company Information



Exhibition

2018 CeBIT Exhibition in Germany/2018 GITEX Exhibition in Dubai



Packaging & Shipping

MODEL  C60K
Unit Size(mm)  820*440*1160
Unit Weight(kgs)  294
Gift Box Size(mm)  /
QTY/CTN  1 PCS/CTN
Carton Size(mm)  950*560*1333
GW/CTN(kgs)  314
NW/CTN(kgs)  294
Warranty   12 Months
